User Instructions for 4 Scroll Combination Locks - Type P
How to use and re-set 4 scroll mechanical combination lock using master re-set key. This is for a Type P lock.
Step 1 - Set Lock To Default User Code
Scroll the 4 dials into a horizontal position to the default factory user code of 3 3 3 3
Step 2 - Open Up
Turn the complete knob unit 90 degrees to the right to open the locker compartment.
The lock must be in the open position to allow the user to set their own individual code.
The cam arm at the back of the door will be in an upright position when the lock is in the open position.
Step 3 - Setting A New Code
Press and hold the small code set button and whilst continuing to hold, rotate the dials to select a new user code of choice.
Release the code set button and the new user code will be set
Close the locker door and lock the compartment by rotating the lock unit back 90 degrees (left).
Before leaving the locker, scramble the code
The locker compartment is now fully locked
Step 4 - Opening The Locker
Scroll the dials to the 4 digit code previously set by the user.
Open the locker compartment by turning the knob 90 degrees to the right
Leave the locker door open for the next user.
Step 5 - How To Retrieve A Forgotten Code
Insert the master re-set key and turn 90 degrees clockwise. The key should now be in the horizontal position.
Leave the key in place and gently scroll each of the 4 wheels upwards until they stop rotating.
The position of the 4 scrolls will be reveal the previous user code.
Turn the key 90 degrees anti-clockwise and remove from lock.
Open the lock by turning 90 degrees to the right (clockwise)
Step 6 - Start Again To Set New User Code
Refer to step 2 to start the procedure of re-setting a new user code
