Metal Lockers Five Door

Code: P5D

When creating runs of lockers, you can order lockers in Nest of 1, Nest of 2 or Nest of 3 to suit your layout. Nested lockers are joined together side by side in manufacture thus sharing common side panels. Locker nesting is more cost effective and offers easier handling and installation.

What is a nest?


Standard colours
Black
Blue
Multi-Coloured
Probe Autumn Orange
Probe Green
Probe Yellow
Silver
Traffic Red
White
Autumn colours
Probe Autumn Jade
Probe Autumn Lemon
Probe Autumn Ocean
Probe Autumn Purple
Black
Silver
White

£125.89 +VAT

£151.07 inc VAT

Select Extras

Master Key
Probe Master Key Probe Master Key

Master keys for lockers are a handy piece of equipment and should be only issued to supervisors or personnel in charge of lockers.  Access can be gained to many locker compartments with one master key which fits a series of different locks. Providing controlled  access to locker compartments when either keys are lost or access required urgently.

Probe Master Key

£16.00 ea
+vat
Lock
Probe Type A Standard Camlock Probe Type A Standard Camlock

Camlocks provide added security to metal lockers, cupboards and cabinets.  A traditional and cost effective locking method chosen by locker users due to its simplicity and ease of replacement.

  • Users take charge of the responsibility of locking via keys (2 keys supplied with lock)
  • Camlocks are a no cost option when purchasing lockers from 3d Lockers
  • Choose your locking option at checkout or call us for pricing of your locker requirements.

Replacement Camlocks

  • Replacement locks and keys available by calling our sales team on 01924 240291



Probe Type A Standard Camlock

£0.00 ea
+vat
Probe Type B Swivel Hasp & Staple Lock Probe Type B Swivel Hasp & Staple Lock

Hasp and staple latch locks are an ideal locking solution which transfers the responsibility for locking to the user.  The user is required to secure the locker with a padlock.  This system provides flexibility particularly in schools or areas where keys could easily be lost.

  • Hasp and Staple swivel latch locks are available as a no cost option and can be selected just before checkout.
  • Chrome swivel handle with circular cut out to accomodate padlock
  • Locker is opened by turning oval handle 90 degrees to release cam.
  • Ideally a padlock with a 6mm to 7.5mm diameter should be used, with a top shackle dimension of between 19mm and 25mm.
  • Replacement hasp and Staple locks are available by contacting our sales team on 01924 240291

Probe Type B Swivel Hasp & Staple Lock

£0.00 ea
+vat
Probe Type Q Auto Scramble Combination Lock Probe Type Q Auto Scramble Combination Lock

Type Q Auto Scramble Combination Lock

This lock is ideal for settings where the same person uses the same locker compartment on a regular basis.

4 scroll combination lock with 10,000 combinations. Can be used with a master re-set key to find the previous code.

The dials return to 0000 automatically when unlocked to safeguard against code tampering.

Probe Type Q Auto Scramble Combination Lock

£21.09 ea
+vat
Probe Type H Coin/Token Return Lock Probe Type H Coin/Token Return Lock

Coin return locks factory fitted to lockers. Provides increased control over key loss.  Key is held captive until coin is inserted.  Key is then used to lock the door. When the door is opened once again the coin is returned to the user via a tray and the key is held captive once again.

  • 2 keys supplied per lock.
  • Key held captive until coin inserted.
  • Replacement coin return locks available

Probe Type H Coin/Token Return Lock

£24.44 ea
+vat
Probe Type L Digital Combination Lock Probe Type L Digital Combination Lock

The digital combination lock is simple to program, has 40,000 combinations and has emergency access using a master reset code.  Single user is supplied as standard but a multi user option is available.  The batteries last up to 50,000 operations.  Manual master override key is available at checkout.

This lock can also be used horizontally (subject to minimum order quantity).

Auto lock and unlock programming available

Probe Type L Digital Combination Lock

£55.48 ea
+vat
Other
Wrist bands Wrist bands

3D locker adjustable plastic wrist bands providing secure storage for locker keys. Wrist straps available in 7 colours and numbered to choice.  Suitable for wet and dry areas. Supplied with free punch to suit most key types.

Key Types include:  Ronis, Lowe and Fletcher, Assa, Ojmar (Some slight adjustments may be necessary on Probe locker keys)

Large easy to read numbers.

Includes Punch, block and rivet set.

Download  available on tab for assembly instructions



Price:  £3.10 each + VAT if ordered with lockers with additional £10+ VAT P&P if ordered seperately.

Wrist bands

£3.00 ea
+vat
  • Ideal for storing personal items such as mobile phones, wallets or keys
  • Choose from white, silver or black frames
  • Choose lock options
  • Accessories can be added at the chckout including number plates and key fobs
  • FREE delivery to most of UK mainland (orders over £150)
  • Delivery to ground floor entrance or nearets off-loading point*
  • Delivery: 5-15 working days
  • Leadtimes are an indication only and may increase/decrease depending on manufacturing capacity.
  • Installation of lockers - it is important to install your lockers in a safe and secure manner, please see our locker installation guide.

Request Callback

Enhance your workplace with our five door metal lockers.  Manufactured in the UK, these 5 door metal lockers are the benchmark storage locker for durability, reliability and value, especially when space is at a premium.  With an eye pleasing design and pre-drilled carcass for further nesting on site into banks of lockers, our five door lockers are suited to staff rooms, offices and workplace environments such as care homes, school staffrooms,   hospitals, nurseries, retail shops, cafes, bars, restaurants and hotels.

Ideal for storing small handbags, car keys, watches, cameras and mobile phones, these five tier lockers are sleek and stylish.  Being able to accommodate five people’s possession securely in a 30cm area is no mean feat, especially when each compartment is fully accessible by adults with the top locker lock being no higher than 1545mm.

Installation is quick and simple too. Call our sales advice desk for further help.

Fittings included as standard

  • Four intermediate fixed shelves
  • Clear opening: Width of locker - 64mm for framework

Features of metal lockers include:

  • All round reinforced doors, spot welded at corners to give enhanced strength
  • Welded vertical channel section stiffens the door for protection against impact damage.
  • Complies with BS 4680excluding size specification
  • High quality durable paint finish
  • Interframe locking with a cam engaging into the frame providing additional security
  • Lock cover plate designed to accept compartment numbering and identification
  • Carcass ventilation, top and bottom
  • Over 2000 differs on standard locks
  • Active Coat anti-bacterial coating to surfaces
  • UK manufactured
  • Pre-drilled for nesting into runs of lockers on site
  • Choice of locker widths and depths on drop down box - select your size and nesting option
  • Other sizes on request

 Nesting

  • Lockers can be purchased joined together in Nest 1, 2 or 3 for further economy.
  • Nesting Bolts Available to add on at check out, please note 4 nesting bolts needed per side should you want to nest more than 3 lockers together (recomended that all lockers are some way nested together for saftey reasons)

Door Colours:

  • Available in any of the above colours
  • Multi-coloured door combinations available to your choice.  Either random or a set pattern.  Just tell us what you want when ordering.
  • Please check the delivery tab for lead times.

Standard Lock Options:

  • Camlock with 2 keys (over 2000 differs)
  • Hasp and staple latch lock (for use with own padlock)
  • Both these locks are included free of charge and can be selected at basket
  • Supervisor masterkey override available at basket
  • Coin locks unavailable on autumn colour range.
  • Check out our lock options on the locking option tab above

* Nearest off-loading point determined by driver. Driver not insured to carry up stairs or use lifts. Single driver vehicle – assistance will be required for off-loading for larger orders.





Delivery to Home Addresses: Sorry but we are unable to deliver this product to home addresses.

Please Note: The vast majority of our products are manufactured to order and cannot be taken back into stock or exchanged after delivery. Further for further information please contact us.

Code Height Width Depth
701212/5 1780mm 305mm 305mm
701215/5 1780mm 305mm 380mm
701218/5 1780mm 305mm 460mm

Dimensions

Height:    1780 mm

Sizes:      305W x 305D, 305W x 380D, 305W x 460D

All 10 day delivery

Other sizes available:

Nominal Clear Entry Widths:

Locker width -64mm

305mm = clear entry 241mm

380mm = clear entry 316mm

460mm = clear entry 396mm

Overall width of 305mm locker Nest 1 is 305mm, likewise for 460mm

Overall width of 305mm locker Nest 2 = 610mm and Nest 3 = 915mm

Overall width of 460mm wide locker Nest 2 @ 920mm and Nest 3 @ 1380mm

Allow up to 2.5mm per locker for horizontal creep

Compartment Height: 300mm

The locking options below are availble to buy after adding the product above to your basket.

Probe Type A Standard Camlock

Probe Type A Standard Camlock

  • Supplied with 2 keys
  • Additional keys available or easily replaced
  • Master Key for supervisor access available
Probe Type B Swivel Hasp & Staple Lock

Probe Type B Swivel Hasp & Staple Lock

  • Chrome swivel hasp & staple/latch lock
  • For use with own padlock (not included)
  • Keyless solution
Probe Type Q Auto Scramble Combination Lock

Probe Type Q Auto Scramble Combination Lock

Type Q Auto Scramble Combination Lock

This lock is ideal for settings where the same person uses the same locker compartment on a regular basis.

4 scroll combination lock with 10,000 combinations. Can be used with a master re-set key to find the previous code.

The dials return to 0000 automatically when unlocked to safeguard against code tampering.

Probe Type H Coin/Token Return Lock

Probe Type H Coin/Token Return Lock

  • Ideal for single or multi-users
  • £1 coin or token inserted to release key
  • Coin/token returned to user
  • Unavailable on autumn colour range
Probe Type L Digital Combination Lock

Probe Type L Digital Combination Lock

  • 40,000 Combinations
  • Emergency access using service key
  • Easy to use

The accessories below are availble to buy after adding the product above to your basket.

Probe Master Key

Probe Master Key

  • Overrides standard locks
  • Controlled issue key allowing supervisor access to locked compartments
  • Lock type to be Lowe and Fletcher or Ronis
Probe Plastic Number Plates

Probe Plastic Number Plates

  • Suitable for PROBE lockers
  • Plastic number plates with white backgrounds and black lettering
  • Slips neatly into plastic holder plate on locker door and reveals itself as a round disc
  • Ideal for locker identity
Probe Integral Sloping Top

Probe Integral Sloping Top

  • Additional sloping top fitted above locker
  • Stops litter or heavy bags accumulating above the locker
  • Factory fitted or retro fitted.
Probe Engraved Key Fob

Probe Engraved Key Fob

Key fobs to attach to locker keys for locker identification.

Probe Locker stands 150mm

Probe Locker stands 150mm

Wrist bands

Wrist bands

  • Adjustable plastic wrist straps
  • Suitable for all environments including wet areas.
  • Choice of 7 colours, numbered to choice or plain
  • Most major keys can be fitted (minor adjustments with Probe locker keys have to be made)
Padlock 3 scroll combination

Padlock 3 scroll combination

P Series Installation Nesting Bolts Pack of 100

P Series Installation Nesting Bolts Pack of 100

Serious injury could be caused by locker or cupboard tip over.  It is important to install your lockers or cupboards side to side, back to back and back to wall. Nesting bolts to suit probe lockers, please note 4 nesting bolts per side required. Nesting Bolts are supplied as packs of 25, please calculate how many nesting bolts required and order accordingly. Please see our installation guide https://www.3dlockers.co.uk/guides/how-to-install-lockers/

Delivery

Standard Delivery (UK Mainland only)
Estimated delivery is 5-15 working days. Mon - Fri 8.30am to 5.00pm.

Standard Delivery Cost (UK Mainland)
FREE DELIVERY on orders over £150.00+vat. A £25.00+vat carriage charge will be applied if the order value falls under this amount.

Standard Delivery (Non UK Mainland)
Delivery to extremities and offshore locations is available by arrangement and at an extra cost.

Delivery To Home Addresses: Sorry but we DO NOT deliver to home addresses at this time. If we deem a delivery is to a home address, we will automatically cancel and refund the order within 5 working days.

Larger orders: The delivery lead time for larger orders could be extended. Please call us on 01924 240291 for up to date delivery times.

Returns Policy: These lockers are manufactured to order. Once in the production stage they cannot be cancelled, returned or exchanged.

Off Loading: Delivery is to a ground floor point only. Driver assistance for offloading will be required for large deliveries.

See our full delivery and returns policy.

Installation

Installation Service
Our installation service is available on this product. Please call our friendly sales team on 01924 24291 for more up to date information.

* Subject to area, subject to order quantity.

});
